Doors for administrative buildings

Technical description of wooden door blocks manufactured by UE "SOKKOM" for installation at administrative facilities

All elements of the door block (box, trim, leaf, portal expander, glazing frames, false slats) are lined with 0.5 mm thick CPL plastic with a tolerance of +-0.1 mm. The door leaf coating is resistant to ultraviolet radiation, as well as to chemical reagents and detergents (test report for finishing coating).

Door leaf without surfacing or with surfacing (according to the TOR) - a frame made of solid pine, lined on both sides with MDF boards, 6 mm thick, laminated with 0.5 mm thick CPL plastic with a tolerance of +-0.1 mm (color is additionally agreed according to the SLOTEX catalog). Both ends, top and bottom of the canvas are covered with PVC edge 2 mm thick to match the color of the plastic. In glazed door blocks, tempered glass with a thickness of 4-6 mm, reinforced or safety multilayer (triplex) can be used.

The door block box is made of solid pine wood with a rubber seal pressed into the recess of the box profile. A telescopic MDF trim on one or two sides of the door block (according to the TOR), a portal expander for the required wall thickness (if necessary according to the TOR). The coating is 0.5 mm thick CPL plastic with a tolerance of +-0.1 mm (the color is additionally agreed according to the SLOTEX catalog). Door blocks with a threshold are equipped with an aluminum lining. Door blocks, including smoke-proof ones, can be equipped with a floating threshold system if necessary.

The door blocks are equipped with fittings: hinges with a 3-piece bearing /leaf, Lob lock, push handle, cylinder fittings from European manufacturers, door closer if necessary.

Door blocks, including smoke-proof ones, can be made complete with an electric safety lock (access control system), with an "Anti-panic" system.

Technical description of combined door blocks manufactured by UE "SOKKOM" for installation at administrative facilities

The boxes are made of galvanized steel 1.5mm thick. The boxes can be angular (trim on one side), telescopic (crimped to the wall thickness), sliding (in the center of the opening), reverse angular, etc. The hinges and lock sockets are equipped with protective shields welded into the box to protect it from contamination during wall mounting. Each box is equipped with a rubber seal pressed into the recess of the box profile. The box is powder-coated in RAL color (optional).

The surfaced door leaf is a frame made of solid pine, lined on both sides with MDF boards, 6 mm thick, laminated with CPL/HPL plastic 0.4 mm - 1 mm thick. Both ends, top and bottom of the canvas are covered with PVC edge 2 mm thick to match the color of the plastic. The color is additionally matched according to the Slotex catalog.

The door blocks are equipped with fittings: hinges with a 3-piece bearing /leaf, Lob lock, push handle, cylinder fittings from European manufacturers, door closer if necessary.

Door blocks, including smoke-proof ones, can be made complete with an electric safety lock (access control system), with an "Anti-panic" system.
